10000CPH 6 Heads Automatic Can Sealing Machine/ Tin Can Seamer

Principle:

Cans will go to the can sealing machine through conveyor. The dia plate will turn the cans under lid loading head , the lid will be loaded on can mouth automatically with the can checking sensor. With the motor driven energy, the can which already be loaded with lid will go forward to sealing position. With the lifting cam, the sealing head can go up and down when cans come and go. The sealing head will go down to press on the can when the cans come; The sealing head are composed with 2 groups of sealing wheels around one circle, the 2 groups of wheels will turn rapidly together with sealing head in the same direction to process sealing job. The whole system will finish edge rolling job.

The sealing wheels are in 2 step sealing model to make sure the the can edge and lid edge close tightly. Then the sealed can will be suitable for all kinds of liquid, no leakage.

Whole machine is made by SUS304.

Characters:

1, Long lid loading rail to hold more lids to short lid adding time;

2, Ingenious lid loading device to make sure no can, no lid loading, no sealing;

3, Energy saving model, one motor can process all actions;

4, Full sealing effect make sure to be suitable for liquid packing can;

5, The machine suitable for all kinds of cans with same diameter, height can be adjusted easily;

6, Compact construction, only need small space to use the machine;

7, Delivered with whole machine, no need commissioning again after delivery;

Parameters:

Applicable product: drink can, food can, etc.

Applicable cans: tin can- Aluminum can- Plastic can -Paper can

Applicable lids: round 200-209, machine need to be customized for lid 211-603

Capacity: max 10000BPH for cans which diameter≤86mm(adjustable)

Number of sealing head: 6

Power: 8.6KW

Dimension: 1800*1600*2100mm

Weight: 2500KG

Components:

Delivery time:

The machines will be made within 20 working days after the bottle design are confirmed;

Payment:

30％ T/T deposit within five days after the contract is signed against invoice of the seller.

The balance of 70％ T/T before shipment;

Guarantee:

We response for one year warranty for the machine, however, it without any human conduct. And provide one-year free spare part for client. And send engineer to client’s company with client’s provision for flight charge and accommodation. Help install the machine, teaching their staff operate the machine and also, we do have a private school which help our client sending their staff to china, help them training.
