    Mineral Drinking Water Filling Machine 3000BPH With PLC Control

    Ask Lasest Price
    Brand Name : FillPack
    Model Number : CGF8-8-3
    Certification : CE / ISO9001
    Price : 11500USD/unit
    Payment Terms : L/C, D/A, D/P, T/T, , MoneyGram
    Supply Ability : 10 Sets Per Months
    Delivery Time : 25 Working Days After Deposit
    • Product Details
    • Company Profile

    Mineral Drinking Water Filling Machine 3000BPH With PLC Control

    Fully Automatic 3 in 1 Small Bottle Mineral Pure Drinking Water Filling Machine


    CGF8-8-3
    Product Capacity:2000BPH@500ml
    Product Features:
    1. The PET 3 in 1 rinsing filling capping machine is used in production of non-soda drink of mineral-pure water packed in polyester bottles. Washing, filling and capping are integrated in one machine.

    2. The most advanced technology from Japan and Germany is employed in the design. The gravity fixed liquid surface filling is used.The filling is fast, the amount of liquid is accurately controlled and the dropping and leakage are avoided.

    3. Spring cramps are used in the bottle washing process. The empty bottles can be turned over 180~ along the conveying rail. There are two times of internal and external washing, the efficiency of bottle washing is high.
    4. The magnetic torque is used for screw capping. The power of screw capping can be adjusted without steps. The power of the screw capping can also be fixed, and the caps will not be damaged, the capping is reliable.

    5. The whole machine is controlled by PLC with touch-screen as the human-machine interface. The amount of the drinks in the storage tank can be controlled automatically. The filling and capping will be stopped automatically when there is no bottle. When bottles are cramped wrongly or when caps are not available, the machine can be stopped automatically.

    6. The frequency changing technology is used to adjust the operation speed sleeplessly. The production capacity can be displayed digitally and can be adjusted conveniently.
    Technical Parameters:
    Model
    CGF8-8-3
    Dimensions
    1800*1500*2300mm
    Capacity
    2000BPH
    Bottle Type
    PET Bottles
    Filling Range
    200ml---2000ml
    Cap Type
    Plastic Screw Cap
    Voltage
    220/380V
    Suitable For
    Non-carbonated Water

    Mineral Drinking Water Filling Machine 3000BPH With PLC Control
