    Carbonated Drink Beverage PET Plastic Glass 3 In 1 Monobloc Bottle Production Machine / Equipment / Plant / System

    Ask Lasest Price
    Brand Name : FillPack
    Model Number : DCGF32-32-10
    Certification : CE & ISO & TUV & SGS
    Price : 120000USD
    Payment Terms : L/C, D/A, D/P, T/T, , MoneyGram
    Supply Ability : 20 sets/month
    Delivery Time : 30 Working Days After Receiving Your Deposit Payment
    • Product Details
    • Company Profile

    Carbonated Drink Beverage PET Plastic Glass 3 In 1 Monobloc Bottle Production Machine / Equipment / Plant / System

    Description of DCGF32-32-10 Plastic Bottle Filling machine
    Teachnical parameters of DCGF32-32-10
    Filling precision
    ≤+/-1mm(liquid level)
    Filling pressure
    ≤0.4MPa
    PET bottle specification
    (Bottle diameter)50-115mm (Height)160-320mm
    Suitable cap shape
    Plastic or other material screw cap
    Filling temperature
    0℃—5℃
    Our family of plastic bottle carbonated filling machine
    There's always one suitable for you
    Model
    Rinsing filling capping heads
    Capacity(BPH)
    Power(kw)
    Weight(Kg)
    Dimension(mm)
    DCGF12-12-4
    12/12/4
    2000-3000
    4.4
    2500
    2250*1650*2250
    DCGF18-18-6
    18/18/6
    3000-5000
    5.2
    3500
    2600*1965*2250
    DCGF24-24-8
    24/24/8
    5000-7000
    6.2
    4500
    2980*2200*2250
    DCGF32-32-10
    32/32/10
    7000-10000
    6.2
    6000
    3880*2200*2250
    DCGF40-40-12
    40/40/12
    10000-15000
    7.5
    7200
    4000*2250*2500
    DCGF50-50-15
    50/50/15
    16000-20000
    11
    10000
    5500*2250*2500
    DCGF60-60-15
    60/60/15
    20000-24000
    15
    11500
    6500*5500*2550
    If you need glass bottle carbonated filling machines, please check them on our website or contact the sales consultant directly. Please find the contact information at contact us.
    >>>Our machine have so many characteristics:
    ★1, Structural hygiene: All parts in contact with beverages are made of high quality stainless steel, all liquid and gas pipes are polished inside and outside, and all seals in contact with beverages are made of nitrile rubber or silicone rubber for food, which meets the hygienic requirements.
    ★2, The structure of the capping machine is advanced: the capping head adopts magnetic capping, adjusts the required torque according to different caps, and is suitable for various types of plastic caps; the capping machine adopts tooth-shaped device, and the lower cap slideway is equipped with cap detection device to ensure that there is no back cap and no bottle without capping.
    >>>Working process:
    ★In the sealing part, crown caps are commonly used for carbonated beverages in glass bottles, and the sealing effect is very good. The whole capping mechanism is cylindrical. It rotates 360 degrees according to the center of the spindle. The bottle is automatically capped, and then enters the capping mechanism. The capping head operates along a specific guideway and moves up and down in a straight line. When the bottle with the cap is under the cap, the cap is compressed by the cap, and then output by the conveyor chain plate to complete the whole washing, isobaric filling and capping process.
    Bottle capping
    1)The expert improve the design of magnetic steel, this improvement can reduce the defective rate of capping better and the traditional character of easy to set and adjust the torque of screwing capping head.
    2)The device which can take out the reverse cap and prevent the reverse cap passing is settled in the cap-falling guide.
    3)A group of photoelectric switches are settled on cap-falling guide. The machine will stop when there is no cap on the guide.
    4)A bottle inlet detect switch is settled on the screwing capper.
    5)By adjusting the height of the rotary parts to adapt for different bottle height.
    6)The main parts of the screwing capper are processed by the digital-control processing center
